Heat Seal 5500 gas

Heat Seal 5500 gas

Used Heat Seal 5500 gas for sale.  Please call 763-208-2266 for more details and pricing


OUTPUT: Cellulose 135 bags/hr. (4,050 lbs. - 1,840 kg.), Fiberglass 82 bags/hr.   (2,952 lbs. - 1,342 kg.), Rockwool 100 bags/hr.  (3,600 lbs. - 1636 kg.)

 POWER: 24 HP Onan LX990 motor

 DOUBLE  CLUTCH:  Electro-Magnetic double clutches allow air and material flow to be controlled individually by remote control.  Expected life 10 to 15 years.

 SAFETY CLUTCH:  Safety clutch will slip if foreign material (eg. knives or bolts) jams the machine.

 POWER CONTROLS:  Motor mounted ignition switch, choke, throttle control and digital tachometer, hourmeter.

 REMOTE CONTROL:  Box mounted on side of machine.  Totally separate from ignition system.  Relays are plug in type.  150' remote cord supplied.

 AIR CONTROL:  Bleed off valves can be operated independently.  One way air valve prevents insulation from backing up into blower.


 HOPPER: 50-cubic foot capacity, made with heavy gauge metal with heavy-duty reinforced feeder paddles for uniform material feed.

 SHREDDER: Double shredder with self-cleaning tines.

 AIRLOCK CHAMBER:  Rotary type, plate steel construction (wear resistant), 20" long with 12" diameter with 4" outlet.  (3-1/2" hose can be used with an adapter).

 BLOWER:  Positive displacement 4L rotary lobe blower.  7 psi 433 CFM.

 DIMENSIONS: 48 1/2" wide, 72" long, 60" high.  Shipping weight: 1,485 lbs.

 INSTALLATION:  When installed correctly, only outside air is used for: Cooling of Gas Engine, Engine Carburetor, Blower Intake
